OMA OPTICAL MODULATION ANALYZER - SPECIFICATION SHEET

March 23, 2023
Get the most out of your investment with Tektronix oscilloscope’s scalable architecture. Use the stack as a single 70GHz OMA system today then use it as four independent oscilloscopes tomorrow.
Screen Shot 2021 10 22 At 12 56 59 Pm 6172eda3704a3 641cbf13675cf

DOWNLOAD NOW

The industry’s most flexible OMA system is here.

Whether you are working with 100G coherent transceivers or 1 Terabit long haul communication systems, our OMA can be configured to suit your exact requirements.

  • Up to 70GHz of system bandwidth
  • Characterize 400ZR and 800ZR signals up to 140GBaud
  • Supports single and dual polarization PSK and QAM formats
  • Visual signal analysis using constellation and eye diagrams
  • Performance parameter measurement including EVM, BER, Bias errors and more
  • Two built-in narrow linewidth tunable lasers for receiver hardware self-calibration
