Agilent improves J-BERT functionality

JANUARY 9, 2007 - Software release 4.5 and other enhancements enable Agilent's J-BERT to produce the industry's fastest jitter tolerance test results for multi-gigabit transceiver characterization, say company representatives.

Th 234999

JANURY 9, 2007 -- Agilent Technologies Inc. (search for Agilent) today introduced software release 4.5 for the Agilent J-BERT N4903A high-performance serial BERT, which it claims enables test engineers to retrieve the fastest jitter tolerance test results.

The next generations of multi-gigabit devices are emerging throughout the computer, storage, and communications industries. Design and validation teams require new test tools that allow efficient and accurate characterization and conformance testing for these high-speed interfaces, say Agilent representatives, who note that J-BERT improves jitter tolerance testing of these gigabit receivers.

According to the company, J-BERT (search for J-BERT) is the only complete jitter tolerance test offering with built-in and calibrated jitter sources. Automated jitter tolerance tests significantly reduce the programming effort.

The new J-BERT software 4.5 provides the following benefits:
• One-click jitter tolerance test insight with one-screen results that show all tested points and the test limits;
• Faster device debug with restore of jitter setup by clicking on tested points in the jitter tolerance result screen;
• Quicker documentation of test results with the new all-inclusive jitter tolerance compliance report in HTML format;
• Worst-case testing of computer bus devices with SSC (Spread Spectrum Clocking); SSC can be enabled during the automated jitter tolerance tests; and
• Convenient Web-based access to J-BERT's user interface from any remote Web location with the new Web server. J-BERT can be operated in far distance, noisy, or environmental test labs even if the user is offsite and has no knowledge of instrument programming.

Agilent says its new one-click-results software further accelerates jitter tolerance insight with a one-screen result display that shows all passed and failed tested conditions as well as specification limits. A jitter setup now can be restored simply by clicking on tested points. For quicker test documentation, J-BERT now generates all-inclusive jitter tolerance compliance test reports in HTML format.

"Design and validation teams require the most accurate and efficient test equipment to ensure new designs operate robustly and are available in time," explains Siegfried Gross, vice president and general manager of Agilent's Digital Verification Solutions division. "Agilent demonstrates its leadership by continuously providing a complete set of best-in-class tools for physical layer testing for the next generation of gigabit technologies."

In addition to the new "one-click jitter tolerance test results," all J-BERTs are now equipped with an improved clock data recovery (CDR) for the error detector. To support emerging and proprietary data rates, the built-in CDR operates over the complete range of 1 Gbit/sec to 12.5 Gbits/sec. For optimizing the jitter budget and making tests under compliant CDR conditions, the option CTR "compliant CDR with tunable loop bandwidth" is available. Installed J-BERTs can be upgraded to the new CDR functionality.

The new software revision 4.5 for the Agilent J-BERT N4903A high-performance serial BERT is available now as a free download from the Web at www.agilent.com/find/jbert. The new clock data recovery capabilities also are available now for shipment. The option CTR for the compliant and tunable loop bandwidth is priced at $21,000.


Visit Agilent Technologies

Learn more about the test and measurement industry at Lightwave's Test & Measurement Resource Center.Th 234999

The J-BERT software release 4.5 features one-click jitter tolerance test insight with one-screen results that show all tested points and the test limits.
