Visual fault locator from Arden Photonics emphasizes ease of use

Arden Photonics says its new VFI-1200 interferometric inspection system is specifically designed for checking the end-face quality and flatness of cleaved, polished, or lensed fibers with diameters of 125 µm to 1200 µm.

Content Dam Etc Medialib New Lib Lw Online Articles 2011 05 Vfi03

Arden Photonics says its new VFI-1200 interferometric inspection system is specifically designed for checking the end-face quality and flatness of cleaved, polished, or lensed fibers with diameters of 125 µm to 1200 µm.

Thanks to a 5M pixel camera with a x6 digital zoom, the VFI-1200 displays crisp end-face images; high contrast fringe patterns make it easy to estimate end angles, Arden asserts.

The VFI-1200’s software package enables users to grab, save, and print images for recording QA data and produce reports. Other software features include:

  • intensity line profile
  • intensity histogram
  • auto-optimization of intensity
  • end angle estimation
  • pseudo-color rendering
  • review stored images.
