Photline intros 10-GHz RF driver for LiNb03 modulators

JUNE 28, 2007 � The DR-GA-10-HO is a high-power RF driver amplifier module designed to offer a unique combination of bandwidth and output voltage. It delivers up to 11 V peak-to-peak from 50 kHz to above 10 GHz.

Th 251244
Th 251244

JUNE 28, 2007 � The DR-GA-10-HO is a high-power RF driver amplifier module designed to offer a unique combination of bandwidth and output voltage. It delivers up to 11 V peak-to-peak from 50 kHz to above 10 GHz.

Photline (search for Photline) says its high output voltage makes it ideal for optical transmission with formats using 2 x Vπ modulation (DPSK, QPSK, PSBT) and for driving phase modulators over several Vπ.

The DR-GA-10-HO is designed to be high performance and user friendly: It connects directly with Photline modulators (no need for additional connecting RF cables), it uses a single voltage power supply for convenience and safety, and it features a gain control input.
